Denon AVR-X4000 Service Manual

Conrmation item FL display settings Contents of conrmationRemarks
A11
Bi-AMP (signal)Path
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : 5.1ch (Bi-Amp)
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Surround Back L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A14
Front Height (signal) Path
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : 7.1ch (SB/FH/FW)
Speaker Select : Front Height
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Front Height L/R)
·Analog input
⇒
Preout output (Front Height L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A15
Front Wide (signal) Path
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : 7.1ch (SB/FH/FW)
Speaker Select : Front Wide
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Front Wide L/R)
·Analog input
⇒
Preout output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A20
Front Amp-Front Heigh (signal) Path
A 2 0 : F - A M P H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : 9.1ch (SB/FH/FW) - Main Pre-amps : Front
Surround Parameter - Speaker Select : SB/FH
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Front Height L/R)
·Analog input
⇒
Preout output (Front Height L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
A21
Front Amp-Front Wide (signal) Path
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode: MULTI CH STEREO
Amp assign : 9.1ch (SB/FH/FW) - Main Pre-amps : Front
Surround Parameter - Speaker Select : SB/FW
ZONE2 OFF
ZONE3 OFF
·Analog input
⇒
Speaker output (Front Wide L/R)
·Analog input
⇒
Preout output (Front Wide L/R)
(
b
As the input source, you can switch from CBL/SAT to other ones.)
g.18
g.19
g.20
g.21
g.22
30

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
