Specifications – Audio Section
HOME
Audio section
Power amplifier
Rated output
Front
125 W + 125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center
125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.)
165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround
125 W + 125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back / Height1 / Front
wide/Height2:
125 W + 125 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D.)
165 W + 165 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Dynamic power
130W x 2-channel (8 Ω/ohms)
190W x 2-channel (4 Ω/ohms)
Output connector 4 – 16 Ω/ohms
Analog
Input sensitivity/Input impedance 200 mV/47 kΩ/kohms
Frequency response 10 Hz – 100 kHz — +1, –3 dB (Direct mode)
S/N 102 dB (IHF–A weighted, Direct mode)
Distortion 0.005 % (20 Hz – 20 kHz) (Direct mode)
Rated output 1.2 V
Digital
D/A output
Rated output 2 V (at 0 dB playback)
Total harmonic distortion 0.008 % (1 kHz, at 0 dB)
S/N ratio 102 dB
Dynamic range 100 dB
Digital input Format Digital audio interface
Phono equalizer
Input sensitivity 2.5 mV
RIAA deviation ±1 dB (20 Hz to 20 kHz)
S/N 74 dB (IHF-A)
Distortion factor 0.03 % (1 kHz, 3 V)
