Denon AVR-X500 - Front Panel Assy

12
1. FRONTPANELASSY
Proceeding: CABINETTOP
→
FRONTPANELASSY
(1) Removethescrews.
(2) RemovethescrewsanddisconnecttheFFC.
(3) Disconnecttheconnectorwires.
View from the bottom
FFC
FRONT PANEL ASSY
CN102
CN104
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachPCBincludedinFRONTPANELASSY.
