3. RADIATOR ASSY
Proceeding: TOPCOVER
→
DIGITALPCBASSY
→
RADIATOR ASSY
(1) Removethescrews.
(2) Removethescrewsthendisconnecttheconnectorwire.
RemovetheRADIATORASSYfromtheCHASSISBOTTOM.
Shooting direction: A
CN503
MAIN PCB
