2.3. Clearing the protection history
Therearetwowaystocleartheprotectionhistory,asdescribedbelow.
(1) Startupthesetinerror(protectiondisplay)modeanddisplaytheerror,thenpressandholddownthe"DIMMER"
button for 3 seconds.
FLD
P R T : D C
 Pressthe"DIMMER
"
button for 3 seconds.
FLD
P R T : C L E A R
 Theaboveisdisplayedandtheprotectionhistoryiscleared.
FLD
N O P R O T E C T
(2) Initialize.(9page.)
b
Ifyouwanttosaveabackup,performthemethodin2.3.(1)above.
WarningindicationbythePOWERLED
Ifthepoweristurnedoffwhenaprotectionincidenthasbeendetected,thePOWERLED(red)ashesasawarning
accordingtotheconditionsinwhichtheprotectionincidentoccurred.
(1) ASO/DC/PowerPROTECTION:Flashesatintervalsof0.5seconds(0.25secondslit,0.25secondsoff)
(2) THERMAL(A/B)PROTECTION:Flashesatintervalsof2seconds(1secondlit,1secondoff)

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
