Denon AVR-X520BT Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
R5305 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5306 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5307 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5308 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5309 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5310 nsp RES, M-OXIDE FILM(1W/47ohm) 1W/47ohm CRG1SANJ470RT 1
R5313 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5314 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5315,5316 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5317,5318 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5319-5322 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5323 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5324 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5325 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5326 252310006537S PTC THEMISTORS, CHIP(85'C) CRTPRF18BE471Q
B
1
R5327 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5329 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5330,5331 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5332 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5401 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5402 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5403 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5404 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5405 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5406 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5407 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5408 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5409 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5410 nsp RES, M-OXIDE FILM(1W/47ohm) 1W/47ohm CRG1SANJ470RT 1
R5413 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5414 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5415,5416 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5417,5418 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5419-5422 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5423 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5424 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5425 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5426 252310006537S PTC THEMISTORS, CHIP(85'C) CRTPRF18BE471Q
B
1
R5427 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5429 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430,5431 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5432 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5501 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5502 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R5503 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5504 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R5505 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5506 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R5507 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R5508 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5509 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5510 nsp RES, M-OXIDE FILM(1W/47ohm) 1W/47ohm CRG1SANJ470RT 1
R5513 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515,5516 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5517,5518 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5519-5522 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5523 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R5524 nsp RES, CARBON(1/5W,270Kohm,J) CRD20TJ274T 1
R5525 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5526 252310006537S PTC THEMISTORS, CHIP(85'C) CRTPRF18BE471Q
B
1
R5527 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530,5531 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5532 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5701 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5702 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5703 nsp RES, M-OXIDE FILM(1W/33ohm) 1W/33ohm CRG1SANJ330RT 1
R5704 nsp RES, M-OXIDE FILM(1W/100ohm) CRG1SANJ101RT 1
R5705 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5706 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5711 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5712,5713 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 2
R5715-5717 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 3
R5721-5725 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 5
R5726,5727 nsp RES, M-OXIDE FILM(2W/470ohm) 2W/470ohm CRG2SANJ471RT 2
R5728 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R5817-5819 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 3
R7801 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R7802 nsp RES, CHIP(1608/1%/82ohm) CRJ10DF82R0T 1
R7803,7804 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 2
R7806 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7807,7808 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7809-7812 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 4
CAPACIITORS GROUP
C5101 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5102 nsp CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT 1
C5103 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5104 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5105 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5106 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5107 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5108 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5109 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5201 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5202 nsp CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT 1
C5203 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5204 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5205 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5206 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5207 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5208 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5209 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5301 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5302 nsp CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT 1
C5303 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5304 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5305 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5306 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5307 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5308 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5309 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5401 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
7

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
