Denon AVR-X520BT Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
C5402 nsp CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT 1
C5403 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5404 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5405 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5406 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5407 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5408 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5409 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5501 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5502 nsp CAP, MYLAR(100V/470pF/J) 100V/470pF/J HCQI2A471JZT 1
C5503 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C5504 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C5505 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C5506 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C5507 nsp CAP, ELECT(100V/10uF) E3, E1C CCEA2AH100T 1
C5508 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5509 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5605,5606 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 2
C5607,5608 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 2
C5609-5611 nsp CAP, MYLAR(50V/0.018pF/J) HCQI1H183JZT 3
C5612-5614 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 3
C5701 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1
C5702,5703 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 2
C5704 943134010460S CAP , ELECT (30X35) WITHOUT PLATE ON THE TOP CCET63VKL5682N
K
1
C5706 943134010460S CAP , ELECT (30X35) WITHOUT PLATE ON THE TOP CCET63VKL5682N
K
1
C5707 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C5708 943134010480S CAP, ELECT(100V/100uF) CCEA2AH101E 1
C5710 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5711 nsp CAP, ELECT(6.3V/470uF) CCEA0JH471T 1
C5716 nsp CAP, ELECT(16V/47uF) CCEA1CH470T 1
C5717 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5718-5722 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 5
C5723 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C7714,7715 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C7801 nsp CAP, CHIP(1608, 50V/22pF, C0G)_SAMSUNG 1608, 50V/22pF, C0G CCUS1H220JAS 1
C7804,7805 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C7806,7807 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C7810,7811 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C7812 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7813 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C7814,7815 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 2
OTHER PARTS GROUP
CN503 nsp WAFER , 7P(DIP, 3.96PITCH) CJP07GA90ZY 1
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY 1
CN781 nsp WAFER, FFC(9P-1mm, STRAIGHT) 9P-1mm, STRAIGHT CJP09GA117ZY 1
BK501 nsp BRACKET , PCB CMD1A569-V1 1
BN501 nsp WIRE ASS'Y Locking (YH) (13P,2MM,150MM,#26) CWB1B013150HC 1
BN502 nsp WIRE ASS'Y Locking (YH) (9P,2MM,150MM,#26) CWB1B009150HC 1
BN505 nsp WIRE ASS'Y Locking (YH) (3P,2MM,220MM,#26) CWB4B003220HC 1
BN508 nsp PIN HEADER (09P,1.25mm,STRAIGHT,B-TO-B) CJP09GI281Z 1
ET501 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
JK503 943643102350S 4P PUSH SPK (RW/BB, NO SPCC, 94V-0) CJJ5P038Z 1
JK504 943643102360S 6P PUSH SPK (GBB/BBB, NO SPCC, 94V-0) CJJ5R021Z 1
JK781 90M-YT002940R JACK , BOARD CJJ4S010Z 1
JK782,783 943262100150S MODULE , OPTICAL(RX 16MHz) RX 16MHz CJSJSR1124 2
L5101 943115100310S COIL , SPEAKER ( 0.5UH ) CLEY0R5KAD 1
L5201 943115100310S COIL , SPEAKER ( 0.5UH ) CLEY0R5KAD 1
L5301 943115100310S COIL , SPEAKER ( 0.5UH ) CLEY0R5KAD 1
L5401 943115100310S COIL , SPEAKER ( 0.5UH ) CLEY0R5KAD 1
L5501 943115100310S COIL , SPEAKER ( 0.5UH ) CLEY0R5KAD 1
RY560 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
RY562-564 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU 3
RY586 943682100520S RELAY, 942H-2C-12DS, DC12V, 2C2P CSL4A022ZU 1
TU500 943183100510S TUNER , FM(SCREW : F TYPE), AM , SI4730-D60 E3 CNVYST990-A9U1 1
TU500 943183100520S TUNER , RDS , FM(PAL TYPE) , AM , SI4731-D60 E2 CNVYST990-D8E1 1
TU500 943183100500S TUNER , FM(PAL TYPE) , AM , SI4730-D60 E1C CNVYST990-A2J1 1
VR510 943679100020S RES , SEMI FIXED (1K , B CURVE) 1K , B CURVE CVN12A102B03T 1 *
VR520 943679100020S RES , SEMI FIXED (1K , B CURVE) 1K , B CURVE CVN12A102B03T 1 *
VR530 943679100020S RES , SEMI FIXED (1K , B CURVE) 1K , B CURVE CVN12A102B03T 1 *
VR540 943679100020S RES , SEMI FIXED (1K , B CURVE) 1K , B CURVE CVN12A102B03T 1 *
VR550 943679100020S RES , SEMI FIXED (1K , B CURVE) 1K , B CURVE CVN12A102B03T 1 *
8

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
