Denon AVR-X7200W Service Manual

The circuit around CX870 or CY920 is faulty.
YES
YES
YES
YES
YES
Case of AVR-X7200WA model
Can an output voltage (1.8V) to U609
(DC-DC Conv.) be conrmed?
Can an output voltage (3.3V) to U611
(DC-DC-Conv.) be conrmed?
Can an output voltage (1.2V) to U608
(DC-DC Conv.) be conrmed?
Case of AVR-X7200W model
Can an output voltage (1.9V) to U903
(DC-DC Conv.) be conrmed?
Case of AVR-X7200WA model
Can an output voltage (2.5V) to U610
(DC-DC Conv.) be conrmed?
Are the versions of the Ethernet SBL and IMG displayed in Version
Check Mode?
Is E_POWER1 (U5001 uCOM 53pin)
"Hi" ?
Is E_POWER_4 (U5001 uCOM 56pin)
"Hi" ?
Is E_POWER4 (U5001 uCOM 56pin)
"Hi" ?
Is E_POWER2 (U5001 uCOM 54pin)
"Hi" ?
The circuit of E_POWER1 between
U5001 and Q611 are faulty.
The circuit of E_POWER_4 between
U5001 and U609 are faulty.
The circuit of E_POWER4 between
U5001 and U608 are faulty.
The circuit of E_POWER2 between
U5001 and U6101/U903 are faulty.
The circuit around U609 (DC-DC.
Conv.) is faulty.
The circuit around U611 (DC-DC-
Conv.) is faulty.
The circuit around U608 (DC-DC.
Conv.) is faulty.
The circuit around U6101/U903 (DC-
DC.Conv.) is faulty.
The Ethernet software is faulty.
NO
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES
YES
YES
d
d d d
d
d
110

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
