Denon AVR-X7200W Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Turn the PANEL LOCK and REMOTE LOCK modes on and off.
2.2. Starting up
Hold down buttons "STATUS" and "INFO" at the same time and press the power button to turn on the power.
Select the mode using the button "CURSOR
f
", and press the button "ENTER" to commit the selection.
2.3. Displaying and Selecting Each Mode
The information shown on the display changes each time the button "CURSOR
f
" is pressed.
Press the button "ENTER" to set the currently displayed mode and restart the device.
The On/Off setting for each mode is shown by an asterisk "
*
".
q
FLD
L1
– F P / V O L L O C K * O n
L2
F P L O C K O n
The buttons on the unit and the master volume knob cannot be operated.
w
FLD
L1
F P / V O L L O C K * O n
L2
– F P L O C K O n
The buttons on the unit cannot be operated.
e
FLD
L1
F P L O C K * O n
L2
– F P L O C K O f f
The PANEL LOCK mode is turned off.
r
FLD
L1
F P L O C K O f f
L2
– R C L O C K O n
The device cannot be operated by the remote control.
t
FLD
L1
R C L O C K O n
L2
– R C L O C K O f f
The REMOTE LOCK mode is turned off.
24

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
