Denon AVR-X7200W Service Manual

4. Remote ID Setup Mode
4.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same
room.
4.2. Starting up
Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.
Select the "6. REMOTE ID" using the button "CURSOR
f
", and press the button "ENTER" to commit the selection.
4.3. Operations
(1) When Remote ID Setup mode is started, the following is displayed.
FLD
L1
L2
R E M O T E I D ?
(2) Press the "
QUICK SELECT 1 - 4" button that corresponds to the number you want to set.
Button Display
QUICK SELECT 1
L2
R E M O T E I D 1
QUICK SELECT 2
L2
R E M O T E I D 2
QUICK SELECT 3
L2
R E M O T E I D 3
QUICK SELECT 4
L2
R E M O T E I D 4
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4" and the POWER button on the unit can be used in Remote ID Setup Mode.
4.4. Setting the Remote coutrol unit
(1) Press and hold "
RC SETUP" button for more than 3 seconds.
(2) Use"
d
/
f
"todisplay"
RC-ID
"ontheremotecontrolunitandpress"
ENTER
".
(3) Use "
d
/
f
" to set the remote ID and press "ENTER".
"OK" ashes four times on the remote control unit and the normal operation mode is restored.
NOTE:
If the ID of the unit and remote control do not match, "AVAMP
z
" appears on the display of the unit when the remote
control is used (*: own remote control ID).
75

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
