Denon AVR-X7200W Service Manual

3.9. TUNER STEP mode (E2/E3 only)
3.9.1. Actions
This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed.
3.9.2. Starting up
Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.
Select the "5. TUNER FRQ SET" using the button "CURSOR
f
", and press the button "ENTER" to commit the selection.
3.9.3. Displays
Start this unit in TUNER STEP mode, select using button "CURSOR
0
/
1
" and enter using button "ENTER".
The following information is displayed in the following order.
(1) AM9kHz/FM50kHz selected
FLD
L1
* T U N E R F R Q S e t
L2
< A M 9 / F M 5 0 >
"
CURSOR
0
" "CURSOR
1
"
(2) AM10kHz/FM200kHz selected
FLD L2
< A M 1 0 / F M 2 0 0 >
"ENTER"
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
74

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
