Denon AVR-X7200W Service Manual

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
-20dB
-30dB
-40dB
-10dB
EXT IN
AVR-X7200
LEVEL DIAGRAM
SURR.BACK ch
-10dBFS
-40dBFS
200mV
+30dB
S
P O
U
T
+
29
d
B
＋
EXT IN
＋
SPEAKER
OUT
D
S
P
x3pcs
R2A15220FP
GAIN
ADJ.
PRE OUT
MUTE
AK4490
D/A
－
－
＋
PLD
from
ZONE2
from
ZONE2
DD INPUT:-20dBFS SL+SR 1kHz
(SB:MTRX ON, DD EX MODE)
ANA INPUT:200mVrms L+R 1kHz
(MODE:MULTI CH STEREO)
AK4490
GAIN setting of MASTER VOL 00dB
･DOLBY DIGITAL IN -2.5dB =-2.5dB
･ANALOG IN -2.5dB +3.5dB =+1.0dB
(1) (2) (3)
(1):Basic OFFSET of VOL=0dB
(2):SB ch correction
(3):OFFSET of the AD input
-30dBFS
4
.
2
Vr
ms
/
8Ω
1
5
0
mVr
m
s
PRE O
U
T
200mVrms
0dBFS=1.980rms
F
ULL
S
CALE
L
EVE
L=
2
.00
Vr
m
s
NON
C
L
ICP
M
A
X
SIG
N
A
L
L
E
V
E
L
4
.
0
V
r
m
s
L.P.F GAIN=0dB
200
m
Vr
ms -2.5dB
+1.0dB
-2.5dB EXT IN
198mVrms
140mVrms
-20dBFS(DIG.IN)
-23dBFS(A/D IN)
1
40m
Vrm
s
123

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
