Denon AVR-X7200W Service Manual

u
GUI SFLASH :
FLD
L1
G U I : 7 2 1 Z * * * *
L2
Z
：
Region code(E3/E2/JP=1, E1C=5)
i
Ethernet 1st Boot Loader, Hardware ID :
FLD
L1
E t h e r n e t F B L
L2
* * * * * * - A A
AA
:Hardware ID
o
Ethernet 2nd Boot Loader, Rhapsody Flag :
FLD
L1
E t h e r n e t S B L
L2
* * * * * * * * * * * * * - B B
Q0
Ethernet IMAGE :
FLD
L1
E t h e r n e t I M G
L2
* * * * * * * * * * * * *
Q1
Ethernet MAC ADDRESS information :
FLD
L1
* N E T M A C A d d r e s s
L2
* * * * * * * - * * * * *
Q2
BT MAC ADDRESS information :
FLD
L1
* B T M A C A d d r e s s
L2
* * * * * * - * * * * * S
Q3
HD Radio :
FLD
L1
* H D : S S S S S S S S -
L2
R V V V V . B B B
S
:Software Congration,
R
:Release Type,
V
:Base Version No.,
B
:Build No.
Q4
MultEQ Pro APP :
FLD
L1
* M u l t E Q P r o A P P
L2
* * . * * . * * . * * * *
Q5
MultEQ Pro ICL :
FLD
L1
* M u l t E Q P r o I C L
L2
* * . * * . * * . * * * *
21

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
