Denon AVR-X7200W User Manual

NOTE
0
To operate the Bluetooth device with the remote control of this unit, the Bluetooth
device needs to support the AVRCP profile.
0
The remote control of this unit is not guaranteed to work with all Bluetooth devices.
0
Depending on the type of Bluetooth device, this unit outputs audio that is coupled
to the volume setting on the Bluetooth device.
o
Operations accessible through the option
menu
0
“Pairing with the Pairing Mode” (v p. 101)
0
“Performing repeat playback” (v p. 140)
0
“Performing random playback” (v
p. 140)
0
“Adjusting the audibility of dialog and vocals (Dialog
Enhancer)” (v
p. 144)
0
“Adjusting the volume of each channel to match the input source
(Channel Level Adjust)” (v p. 145)
0
“Adjusting the tone (Tone)” (v
p. 146)
0
“Displaying your desired video during audio playback (Video
Select)” (v p. 147)
0
“Playing the same music in all zones (All Zone Stereo)” (v
p. 149)
Contents
Connections Playback Settings Tips Appendix
100
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
