5
Use ui p to select the station, then press ENTER.
Playback starts once buffering reaches “100%”.
Operation buttons Function
1
Playback
2
Stop
ENTER (Press and hold) Stop
CH/PAGE d f
Switch to the previous page/next page in the list
display
0
The display switches between track title and radio station name etc. each time the
main unit’s STATUS is pressed.
0
Any characters that cannot be displayed are replaced with “.” (period).
NOTE
The radio station database service may be suspended or be otherwise unavailable
without notice.
Playing the last played Internet Radio
station
1
Press INTERNET RADIO.
The source switches to “Internet Radio” and the last played radio
station plays.
o
Operations accessible through the option
menu
0
“Searching content with keywords (Text Search)” (v p. 142)
0
“Playing back music and a favorite picture at the same time
(Slideshow)” (v p. 143)
0
“Adjusting the audibility of dialog and vocals (Dialog
Enhancer)” (v
p. 144)
0
“Adjusting the volume of each channel to match the input source
(Channel Level Adjust)” (v p. 145)
0
“Adjusting the tone (Tone)” (v p. 146)
0
“Displaying your desired video during audio playback (Video
Select)” (v
p. 147)
0
“Playing the same music in all zones (All Zone Stereo)” (v p. 149)
Contents
Connections Playback Settings Tips Appendix
115
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X7200W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X7200W and is the answer not in the manual?

Denon AVR-X7200W Specifications

General IconGeneral
Receiver typeSurround
Input sensitivity200 mV
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)102 dB
Power output per channel (1KHz@6 Ohm)190 W
Power output per channel (20-20KHz@8 Ohm)210 W
HDMI in8
Audio (L/R) in7
Composite video in5
Digital audio optical in2
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in3
12V triggerYes
Speakers connectivity type-
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Optical drive includedNo
DisplayLCD
Product colorBlack
Audio decodersDolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)780 W
Weight and Dimensions IconWeight and Dimensions
Depth427 mm
Width434 mm
Height196 mm
Weight17800 g
