Denon AVR-X7200W User Manual

8
Use ui to select the folder, then press ENTER.
Favorites :
Displays the favorite photographs of the
specified user.
Photostream : Displays a list of shared photographs.
PhotoSets : Displays the folder (photograph album) list.
Contacts :
Displays the screen name used by the
specified user in Contacts.
Remove this
Contact :
Deletes a user from Flickr Contact.
Add this Contact : Adds a user from Flickr Contact.
9
Use ui p to select the photograph, then press ENTER.
The selected photograph is displayed.
Operation buttons Function
1
Playback
2
Stop
ENTER
Playback
(Press and hold) Stop
u i
Display previous photograph / Display next
photograph
CH/PAGE d f
Switch to the previous page/next page in the list
display
Contents Connections Playback Settings Tips Appendix
123
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
