Denon AVR-X7200W User Manual

Input signal Sound mode
Sound mode
MOVIE MUSIC GAME
Multi-channel
z
3
Stereo
S S S
Dolby Digital
Dolby Digital
S S S
Dolby Digital + Dolby Surround
S S S
Dolby Digital A-DSX
z
4
S S S
Dolby Digital + Neo:X Cinema
S
Dolby Digital + Neo:X Music
S
Dolby Digital + Neo:X Game
S
Dolby TrueHD
Dolby TrueHD
S S S
Dolby TrueHD + Dolby Surround
z
5
S S S
Dolby Atmos
z
6
S S S
Dolby TrueHD A-DSX
z
4
S S S
Dolby TrueHD + Neo:X Cinema
S
Dolby TrueHD + Neo:X Music
S
Dolby TrueHD + Neo:X Game
S
z3
Some sound modes cannot be selected depending on the audio format or number of channels of the input signal. For details, see “Types of input signals, and
corresponding sound modes” (v p. 346).
z4
These modes add new channels to 5.1-channel surround using Audyssey DSX
®
processing. (v p. 202)
z5
This can be selected when the input signal does not contain Dolby Atmos.
z6
This can be selected when the input signal contains Dolby Atmos.
Contents
Connections Playback Settings Tips Appendix
162
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
