Update (DTS:X)
Input signal Sound mode
Sound mode
MOVIE MUSIC GAME
2-channel
z
1 DTS Neural:X
z
2
S S S
Multi-
channel
DTS:X
DTS:X
S S S
DTS:X MSTR
S S S
DTS DTS + Neural:X
S S S
DTS-HD/DTS Express DTS-HD + Neural:X
S S S
PCM multi-channel Multi Ch In + Neural:X
S S S
z1
2-channel also includes analog input.
z2
This mode plays back 2-channel sources in 5.1, 7.1 or 9.1-channel playback. It cannot be selected when headphones are used, or when only front speakers are used.
0
You can select DTS:X or DTS Neural:X if updated to DTS:X.
0
DTS Neo:X is no longer supported once you update to DTS:X.
0
DTS or DTS-HD signal + Dolby Surround up-mixing is not supported once you update to DTS:X. Please select DTS Neural:X for DTS coded material.
0
Dolby or Dolby TrueHD + DTS Neural:X up-mixing is not supported. Please select Dolby Surround for Dolby coded material.
Upgrade (Auro-3D)
Input signal Sound mode
Sound mode
MOVIE MUSIC GAME
2-channel
z
1/Multi-channel
z
3
Auro-3D
z
7
S S S
Auro-2D Surround
z
8
S S S
z1
2-channel also includes analog input.
z3
Some sound modes cannot be selected depending on the audio format or number of channels of the input signal. For details, see “Types of input signals, and
corresponding sound modes” (v
p. 346).
z7
It cannot be selected when headphones are used, or when a speaker configuration without front height speakers is used.
z8
It cannot be selected when headphones are used, or when only front speakers are used.
Contents
Connections Playback Settings Tips Appendix
166
Front panel Display Rear panel Remote Index
