DN-D4500
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
00DGU-3674 MAIN P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3398 003 MN6627933
IC102 00D 262 3159 909 AN8785SB
IC103 00D 262 3160 901 AN22002A
IC110 00D 262 3401 000 64M SDRAM(TSOP)
IC201 00D 262 3398 003 MN6627933
IC202 00D 262 3159 909 AN8785SB
IC203 00D 262 3160 901 AN22002A
IC210 00D 262 3401 000 64M SDRAM(TSOP)
IC301 00D 262 3044 001 MN102H730F
IC302 00D GEN 6951 SYSTEM ROM SUB ASSY 8M FLASH MEMORY(70N)
IC303 00D 262 3513 008 8M FLASH MEMORY(90N) *
IC401 00D 262 3399 002 ADSP-BF531(LQFP)
IC402 00D 262 3407 004 128M SDRAM(TSOP)PBF
IC403,404 00D 262 2640 901 SN74LV245APW-EL2
IC405 00D 262 2959 906 SN74LV244APW +REF
IC406 00D 262 2640 901 SN74LV245APW-EL2
IC408 00D 262 2518 907 SN74LV74APW-EL2 +C
IC409 00D 262 2516 909 SN74LV32APW-EL2 +C
IC410 00D 262 3400 904 TPC6103
IC501 00D 263 0615 902 BA15218F-DXE2 +C
IC502 00D 262 1953 903 TC7WU04F +C
IC503 00D 262 3166 905 PCM1748E(TAPE) +C
IC504 00D 262 3305 902 SN74LV393APW
IC505 00D 262 1953 903 TC7WU04F +C
IC551 00D 263 0615 902 BA15218F-DXE2 +C
IC552 00D 262 1953 903 TC7WU04F +C
IC553 00D 262 3166 905 PCM1748E(TAPE) +C
TR101 00D 272 0125 904 2SB709A +C
TR102,103 00D 269 0082 902 DTC114EKT96 +C
TR201 00D 272 0125 904 2SB709A +C
TR202,203 00D 269 0082 902 DTC114EKT96 +C
TR501-503 00D 273 0460 905 KTC2875B-RTK +C
TR504 00D 273 0426 907 2SC2412KLNT146 +C
TR505 00D 269 0082 902 DTC114EKT96 +C
TR506 00D 269 0083 901 DTA114EKT96 +C
TR507 00D 269 0082 902 DTC114EKT96 +C
TR551-553 00D 273 0460 905 KTC2875B-RTK +C
TR554 00D 273 0426 907 2SC2412KLNT146 +C
D301 00D 276 0559 909 DAP202KT146 +C
D302 00D 276 0560 901 DAN202KT146 +C
D303 00D 276 0559 909 DAP202KT146 +C
D304 00D 276 0560 901 DAN202KT146 +C
D401 00D 276 0559 909 DAP202KT146 +C
D402 00D 276 0750 902 RB521S-30TE61 +REF
