Denon DN-D4500 - Details of Recycle Parts for Main Unit

59
DN-D4500
Details of Recycle parts for Main unit
＊You have to remove the parts that marked “WEEE Mark ◆ " when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Material Q'ty
1
◆
MAIN P.W.B. UNIT ASS'Y Complex 1
2 POWER P.W.B. UNIT ASS'Y Complex 1
2-1
◆
LED1 UNIT
2-2
◆
LED2 UNIT
2-3
◆
OP/CL UNIT
2-4
◆
POWER UNIT
2-5
◆
CONNECT UNIT
3 CHASSIS Steel 1
4 FOOT SHEET Rubber 2
5 BLIND LABEL PET 2
6 PWB BRACKET Steel 1
7 TRANS BRACKET Steel 1
8 BACK PANEL Steel 1
9 CARD SPACER (L=14.8) PA 66 1
10 SPRING PLATE Steel 2
11 CD MECHA(CD11FTA3N) Complex 2
12 FFC HOLDER ABS 2
13 MECHA BRACKET Steel 2
14 PWB FRAME Steel 1
15 FRAME FIX BRACKET Steel 1
16 CORD BUSH PA 66 1
17 FRONT SUB PANEL Steel 1
18 BLIND SHEET Leather 2
19 FRONT PANEL Steel 1
20 P.SW KNOB GUIDE ASSY ABS+PMMA 1
21 RUBBER KEY (C) Rubber 2
22 SHEET Rubber 2
23 P.SW KNOB ABS 1
24 LOADER PANEL ABS 2
25 TOP COVER PVC+Steel 1
26 CORD HOLDER Complex 1
27
◆
POWER TRANS Complex 1
37
◆
AC CORD W/CON.E2 Complex 1
45
◆
CE04W1C4183MC(SMQ) Complex 1
SCREWS
51 3X6 CBTS(S)-Z Steel 13
52 3X6 CBS-B Steel 4
53 3X6 FHHS MFZNII-B Steel 12
54 3X8 CBTS (S)-B Steel 33
55 3X8 CBTS (P)-B Steel 8
56 3X25 CPTS(S)-Z Steel 4
57 3X32 CBTS-S (B) Steel 4
58 3W-B Steel 12
59 4X8 CBTS (S)-Z Steel 4
60 3P. SWELLING SCREW Steel 4
