DN-D4500
DOCUMENTS FOR WEEE
Details of Recycle parts for Remote control unit (RC-D45)
＊You have to remove the parts that marked “WEEE Mark ◆ " when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Material Q'ty
1 REMOTE P.W.B. UNIT ASS'Y Complex 1
1-1
◆
DISPLAY1 UNIT
1-2
◆
DISPLAY2 UNIT
1-3
◆
RC CPU UNIT
2 RC FRONT SUB PANEL Steel 1
3 RC FRONT PANEL Steel 1
4 LENS PMMA 4
5 WINDOW PMMA 2
6 R.KEY(PLAY/PAUSE) Rubber 2
7 R.KEY(FUNCTION) Rubber 2
8 COVER Steel 1
9 FOOT Rubber 4
10 SHUTTLE RING ABS 2
11 JOG DIAL ABS 2
12 KNOB(MARU) ABS 2
13 SLIDE KNOB ABS 2
SCREWS
51 3X6 FHHS MFZNII-B Steel 6
52 3X6 CBTS(S)-Z Steel 20
53 3X8 CUP SCREW Steel 4
54 M3-SEMS SCREW(6W) Steel 1
55 3W-B Steel 6
