Denon DN-V310 - Serial Remote Control Terminal

４
1 Serial Remote Control Terminal
Remote control of the DN-V310 is possible by connecting the serial interface of a PC, etc., to the serial
remote terminal on the rear panel. The commands usable with serial remote are categorized in three
groups, the PC group controlling the DN-V310, the PS group for acquiring information on the
DN-V310’s operating status, and the PR group of status information issued asynchronously from the
DN-V310 in response to changes in operating status. The details of the commands are described each
group. The DN-V310’s serial remote terminal is compatible with RS-232C standards.
Pin
No.
Signal name Input/Output
（DN-V310）
1 No connection -
2
ＴＸＤ
Output
3
ＲＸＤ
Input
4 No connection -
5
ＧＮＤ
-
6 No connection -
7 CTS Input
8 RTS Output
9 No connection -
Standards Conforming to RS-232C
Connector type D-sub female 9-pin
Synchronization Asynchronous
Baud rate 9,600 bps
Data length 8 bits
Parity None
Stop bit 1 bit
Flow control None
5
1
9
6
NOTES
 Use a male/female serial straight cable to connect to a personal computer.
 To prevent damage to the DN-V310 and the controller, turn off the power of both the
DN-V310 and the controller when connecting the serial cable.
 Also be sure the settings of the control side’s communications specifications (data length,
baud rate, stop bit, flow and parity) match those of the DN-V310 (shown on the table above
at the left).
 The DN-V310 cannot be used with CTS and RTS signals. If such signals are being received
and controlled on the controller, take the proper measures for the controller’s software
and/or hardware.
[ D-sub 9pin female connector ]
DN-V3１0 side
DN-V310 side
