Denon MC2000 - Connections; Input and Output Terminals

10
Disassembl
y
Illustration
10-1.Remove the wheel ass'y*2 .
10-2. Remove the spring & wire ass'y *2 .
11-1. Remove the screws *7 from the bottom base.
11-2. Remove the nut *2 and washer *2 from phone jack.
11-3. Remove the rotary knob(small) *2 .
E-RING
