PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model JP : Japan model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks HANPIN Q'ty New
1 nsp BAR CODE(86*209mm,t=0.1mm) 701-M2000EM-4916 1
2 941403100780P CHASSIS ASSY 701-2000-5159 1 *
3 941403100790P WHEEL ASSY 701-2000-5243 2 *
3-1 nsp WHEEL & SHAFT ASS'Y 701-2000-5160 2
3-2 nsp WHEEL PLATE 300-2000-1833 2
3-3 nsp SPRING(SUS304,
0.3,L=6) 603-M1-384 2
3-4 nsp SCWER(SAE1018,STS,2.0*3) 602-STS2003-677 2
4 nsp BASE ASS'Y 703-2000-1370 1
5 nsp CROS FADER PCB ASS'Y 704-6000-9603 1
6 nsp I/O PCB ASS'Y 704-MC2000-A347 1
7 nsp CONTROL PCB ASS'Y 704-MC2000-A348 1
8 nsp PHONE PCB ASS'Y 704-MC2000-A350 1
9 941412005080P PUSH KNOB(MIDDLE) 100-UDJ3EB-2213 2
10
00D9587012907
ROTATY KNOB(ABS,BLACK) 100-300-2226 1
11
00D9587013401
PUSH KNOB 100-300-2231 3
12 941412005090P ROTARY KNOB
100-6000-2298
2
13 412510031005P ROTARY KNOB 100-1100-2633 1
14 412510032008P ROTARY KNOB 100-1100-2634 12
15 941412005100P ROTARY KNOB 100-6000-2634 1
16
nsp
LED LENS 100-700-2680 3
17 941412100970P JOG KNOB 100-1000S-2736 V 3 *
18 941412100980P KNOB (small) 100-33-2827 2 *
19 941411102010P BUTTON (RECTANGLE) 100-2000-2909 20 *
20 941411102030P BUTTON (CUE) 100-2000A-2909 2
*
21 941411102040P BUTTON (SHIFT) 100-2000B-2909 1 *
22 941411102020P BUTTON (SYNC)
100-2000C-2909
2 *
23 941411102050P BUTTON (VINYL MODE) 100-2000-2910 2 *
24
941411102060P BUTTON (KEY LOCK) 100-2000A-2910
2 *
25
941412100930P BUTTON (AUTO/EXIT+) 100-2000B-2910
2 *
26 941411102070P BUTTON (AUTO/EXIT-) 100-2000C-2910 2 *
27 941411102080P BUTTON (PITCH BEND+)
100-2000D-2910
2 *
28 941411102090P BUTTON (PITCH BEND-) 100-2000E-2910 2 *
29 941411102100P
BUTTON (CIRCLE-S) 100-2000B-2910S
6 *
30 941411102110P BUTTON (CIRCLE-L) 100-2000-2911 2 *
31 941411102000P BUTTON (PLAY/CUE) 100-2000-2912 2 *
32 nsp
FIXED PLATE FOR SLIDE VR(SECC,1.5t)
300-100-1167 1
33 941403100800P TOP PANEL 300-2000-1999 1 *
34 nsp GROUND PLATE 300-2000-2001 6
35 nsp
1P LEAD WIRE(L=45mm,AWM1007,AW
G26,BLACK)
406-PS2-631 2
36 941606501770P 14P 1.0 FFC CABLE(L=200mm) 406-MC2-1207 1 *
37 nsp USB CABLE(L=1500mm) 408-100UG-087 1 *
38 nsp ADHESIVE BACKED MOUNT 504-HDJ7000-032 1 *
39 nsp
CLIP 603-PROS2-256A
2 *
