68
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model JP : Japan model
BK : Black model SP : Premium Silver model
CONTROL P.C.B ASS'Y
Ref. No. Part No. Part Name Remarks HANPIN Q'ty New
SEMICONDUCTORS GROUP
D400-422 nsp
SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A
1
D423 nsp
SWITCHING DIODE( ISS133 T-77) 414-3113-005
1
D424-444 nsp
SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A
1
D445 nsp
SWITCHING DIODE( ISS133 T-77) 414-3113-005
1
D446 nsp
SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A
1
D447 nsp
SWITCHING DIODE( ISS133 T-77) 414-3113-005
1
D448-455 nsp
SWITCHING DIODE(ISS355VM 1.7*1.25MM) 414-CD1000-075A
1
D456-459 941622100050P
SENSOR(LTH-301-07) 417-HDJ2000-411
1
D460,D461 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D462 941263100690P
LED ( L-7104QBD/TB/TD-D,BLUE ) 410-MU12B1-389
1 *
D463 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D464-D467 941263100690P
LED ( L-7104QBD/TB/TD-D,BLUE ) 410-MU12B1-389
1 *
D468 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D469 941263004190P
LED ( LTL1CHJSDNN,YELLOW ) 410-HDJ2000-162
1
D470,D471 941263004180P
LED(YELLOW GREEN,LTL-1CHJGDNN,
∮
3.1) 410-DJ5000-252
1
D472,D473 941263004190P
LED ( LTL1CHJSDNN,YELLOW ) 410-HDJ2000-162
1
D474,D475 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1
*
D476,D477 941263004180P
LED(YELLOW GREEN,LTL-1CHJGDNN,
∮
3.1) 410-DJ5000-252
1
D478 941263004190P
LED ( LTL1CHJSDNN,YELLOW ) 410-HDJ2000-162
1
D479 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D480,D481 941263100690P
LED ( L-7104QBD/TB/TD-D,BLUE ) 410-MU12B1-389
1 *
D482 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D483 941263004190P
LED ( LTL1CHJSDNN,YELLOW ) 410-HDJ2000-162
1
D484,D485 941263100690P
LED ( L-7104QBD/TB/TD-D,BLUE ) 410-MU12B1-389
1 *
D486 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1
*
D487 941263100690P
LED ( L-7104QBD/TB/TD-D,BLUE ) 410-MU12B1-389
1 *
D488-D490 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D489 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D491 941263004190P
LED ( LTL1CHJSDNN,YELLOW ) 410-HDJ2000-162
1
D492-D498 941263100680P
LED(LTL1CHJEDNN,RED) 410-DJ5000-253
1 *
D460-D498 nsp
LED HOLDER(LED3-1A-B,H=1.5mm,BLACK) 504-HDJ2000-097
1
D499 nsp
DIODE(SMAJ6.0A,400W/6.0V,DO-214AC) 414-UDJ200-284
1
D500-503 941209000470S
ESD DIODE(RSB6.8S 150mW.6.8V EMD2 ROHM) 414-DJ1100G-207
1
IC400 941243101300P
CONTROL IC ASS'Y 704-MC2000-A349
1 *
IC402,403 nsp
IC(74HC4052D/74HC4052DT,SMD) 417-QSPAND-432
1
IC404 00D9587058709
IC(74AHC595DR,SOP-16) 417-HDJ9800-643
1
IC405,406 941243004220P
IC(PIC16F616-I/SL,SOIC-16) 417-RMP3-936
1
Q400-405 941212004520P
CHIP TRANSISTOR(2SB1424T100R) 416-MC6000-375
1
Q406-409 941213500220P
TRANSISTOR(TR DTC124EKAT146 SMT3) 416-CDN88-044
1
Q410-417 941214004530P
CHIP TRANSISTOR(2SD1757KT146R,SMT3) 416-MC6000-374
1
ZD400-403 941202500510P
ESD DIODE(EDZCTE616.8B,150MW/6.93V,EMD2) 414-RMP3-285
1
d
CAPACITORS GROUP
C400,401 nsp
CHIP CAPACITOR(0.1uF/50V,Z) 413-DCM280-773
1
C405-408 nsp
CHIP CAPACITOR(3300pF/50V,K,0603 TAP,X7R) 413-DCM280-770
1
C409 nsp
CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889
1
C410,411 nsp
CHIP CAPACITOR(3300pF/50V,K,0603 TAP,X7R) 413-DCM280-770
1
C413 nsp
CHIP CAPACITOR(3300pF/50V,K,0603 TAP,X7R) 413-DCM280-770
1
C414 nsp
CHIP CAPACITOR(0.01uF/50V,J,0603 TAP,NPO) 413-DCM280-889
1
C415 nsp
CHIP CAPACITOR(3300pF/50V,K,0603 TAP,X7R) 413-DCM280-770
1
To Next Page
