Denon MC2000 Service Manual

37
JOG WHEEL is not operating.
(BEND function is not operating.)
Is D5V outputted 11pin, 12pin of CN300
(Refer to Fig.5 of the 40 page.)
Replace IC400.
Connect the FFC (14pin:CN300) correctly.
Check perifery circuit of Q406, Q407, Q408, Q409, replace it
if defective.
When the periphery circuit is correct, replace IC400.
NO
NO
YES
YES
FLOW CHART NO.10 (405-MC2-3058 : CONTROL UNIT)
Is encoder waveform(0-3.3V) outputted to9pin, 10pin, 45pin,
51pin of IC400, when JOG WHEEL is turned.
(Refer to Fig.1 and 2 of the 39 page.)
