Denon MC2000 Service Manual

74
Ref. No. Part No. Part Name Remarks HANPIN Q'ty New
z
F300 941652500240P
CHIP FUSE(1A,63V,1206 TYPE,LEAD FREE) 422-3BPM-070 1 *
JK100 941643102290P
2P RCA JACK(RJ-1078B-10-0320A) 420-HDJ7000-045 1 *
JK101 941643101360P
MIC JACK (6.4,JY-6313-02-340) 420-SMX211-137 1
JK100 941643102290P
2P RCA JACK(RJ-1078B-10-0320A) 420-HDJ7000-045 1 *
JK300 nsp
GROUND PLATE 300-2000-1832 1 *
JK300 941643004210P
USB JACK(USB-B(F),90°,DIP) 420-007USB-150 1
L002,003 nsp
INDUCTOR(3.3UH/2ACDS21010-3R3M) 415-MC2-401 1
L004 nsp
BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 1
L006,007 nsp
BEAD CORE(A70512003, T-26mm) 415-HV3500K-090 1
L008,009 nsp
BEAD(RH03506BT-B-N,TAPING RT) 415-DCM370E3-134 1
L300 nsp
POWER CHOKE(22uH,1.11A) 415-MC6000-356 1
L301 nsp
COMMON MODE CHOKE(WCM-2012-
900T,90Ω/100MHz)
415-JKME3-370 1
L302 nsp
POWER CHOKE(22uH,1.11A) 415-MC6000-356 1
L303,304 nsp
CHIP BEAD(FBMA-11-201209-121T,120Ω/100MHz) 415-IS201-382 1
W100 nsp
4P 2.5 CONNECTOR WIRE(L=140mm,UL1533#28*1C
TS)
404-MC2-3681 1
X300 941141004940P
OSC (XTAL 6MHz,20PF) 427-DJ2500-049 1

Denon MC2000 Specifications

General

Brand	Denon
Model	MC2000
Type	DJ Controller
Channels	2
Crossfader	Yes
Software	Serato DJ Intro
MIDI	Yes
Inputs	1/4"
Outputs	RCA, 1/4"
Audio Interface	Yes
Software Compatibility	Serato DJ, Virtual DJ
