RCD-CX1
* = Negative logic
66 P2_4/AN2_4/A4(/D4/D3) TU_DATA_IN O L TUNER PACK SIRIAL DATA
67 P2_3/AN2_3/A3(/D3/D2) FAN_DET I H FAN detection input L= temperature detection
68 P2_2/AN2_2/A2(/D2/D1) FAN_ON O H FAN DRIVE SIGNAL OUTPUT H=FAN ON
69 P2_1/AN2_1/A1(/D1/D0) TU_MUTE O H TUNER PACK output mute
70 P2_0/AN2_0/A0(/D0/-) TU_CE O H Tuner pack CE
71 P1_7/D15/*INT5
RESERVED O L
72 P1_6/D14/*INT4
PROTECT I
73 P1_5/D13/*INT3
REMOTE I REMOCON
74 P1_4/D12 IPOD_CONNECT I L H=CONNECTED
75 P1_3/D11 IPOD_TRX_ENA O L IPOD COMMUNICATION ON/OFF CONTROL H=COMMUNICATION
76 P1_2/D10 ENABLE O H to ICE PWR (H:Oscillation stop)
77 P1_1/D9 SP_MUTE O L SP Relay control (L=MUTE)
78 P1_0/D8 PRE_MUTE O L PRE AMP SYSTEM L=MUTE
79 P0_7/AN0_7/D7 H/P MUTE O L H/P RELAY (L=MUTE)
80 P0_6/AN0_6/D6 POWER_ON O L SMPS power supply ON control
81 P0_5/AN0_5/D5 SEL_DATA O L Selecter(TC9273CFG)Serial Data
82 P0_4/AN0_4/D4 SEL_CK O L Selecter(TC9273CFG)Serial Clock
83 P0_3/AN0_3/D3 VOL_DATA O L Electron Volume(NJW1194) Serial Data
84 P0_2/AN0_2/D2 VOL_CLOCK O H ElectronVolume(NJW1194)Serial Clock
85 P0_1/AN0_1/D1 VOL_LATCH O H ElectronVolume(NJW1194)Latch
86 P0_0/AN0_0/D0 SEL_STB O H Selecter(TC9273CFG)Serial Strobe
87 P10_7/AN7/*KI3
KEY3 I Not use
88 P10_6/AN6/*KI2
KEY2 I Not use
89 P10_5/AN5/*KI1
KEY1 I BUTTON A/D input
90 P10_4/AN4/*KI0
KEY0 I BUTTON A/D input
91 P10_3/AN3 TUNER STEP I TUNER STEP switch Switch input of skip frequency of TUNER
(For bandwidth identification only for JP model Wide"L":To the TV band,
Narrow"H":TV band none)
92 P10_2/AN2 RDS I RDS presence switch
93 P10_1/AN1 BE_PWR_MONI I BACKEND POWER watch
94 AVSS GND
95 P10_0/AN0 MODEL_ID1 I MODEL ID setting(1)
96 VREF VCC
97 AVCC VCC
98 P9_7/*ADTRG
/SIN4 RESERVED O L
99 P9_6/ANEX1/SOUT4 FL_DA O L FL DATA OUT
100 P9_5/ANEX0/CLK4 FL_CLK O L FL CLICK OUT
