82
RCD-CX1
POINTS OF GREASING
HANARLUD‑321
Shaftallarea
(0.2mg)
HANARLUD‑321
Onlygearcontactarea(0.7mg)
(Notapplybeltandpulley)
HANARLUD‑321
Shaftallarea
(0.2mg)
Grease:EM30L
Onlyaroundthegear(0.7mg)
(Notapplypulley)
Grease:EM30L
Onlyshaftareaofgearaxis
(Notapplybeltandpulley)
(2.0mgeachx2)
Grease:EM30L
SLIDESHAFT
MoveHOUSINGforwardandapplyit
tothebackwardallarea.(17.0mg)
Grease:EM30L
CAMSPRINGtop
(SLIDECAMcontactarea)
(0.9mg)
HANARLUD‑321
TRAYbottom(Groove,Convex)
(0.5mg)
Convexarea
InsideGroove(Bottom,Wall)
Grease:EM30L
SLIDECAM(Upperconvex,Top)
(2.0mgeachx2)
Grease:EM30L
MECHABASEbottom
CAMSPRINGattachmentarea(0.9mg)
MECHABASE
MECHABASEbottom
TRAYbottom
SLIDECAM
Grease:EM30L
Onlyshaftareaofgearaxis
(2.0mgeachx2)
Grease:EM30L(2.0mg)
Grease:EM30L
Bothendssideofbosscontact
areaunderBECABASE‑SLIDECAM.
(7.0mgeachx2)
Grease:EM30L
Shaft(2.0mg)
Grease:EM30L
Bossallarea
(2.0mgeachX4)
Grease:EM30L
SPRINGPLATE‑STEELBALLcontactarea
(0.9mg)
Greasingpositions
Greasingposition
Greasingposition
Greasingposition
About5mm
Greasingposition
Greasingpositions
Greasingpositions
Greasingposition
Greasingposition
Greasingpositions
Greasingpositions
