Denon RCD-CX1 Service Manual

79
RCD-CX1
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
17A nsp SYS/DAMP/DISP UNIT 8U-210024A : JP 1
17B nsp SYS/DAMP/DISP UNIT 8U-210024B : E3 1
17C nsp SYS/DAMP/DISP UNIT 8U-210024C : E2 1
17 SYS/DAMP/DISP UNIT
29 DISPLAY UNIT
27 VOLUME UNIT
37 POWER SW UNIT
28 HEAD PHONE UNIT
39A nsp SMPS/SPT UNIT 8U-210025A : JP 1
39B nsp SMPS/SPT UNIT 8U-210025B : E3 1
39C nsp SMPS/SPT UNIT 8U-210025C : E2 1
39 SMPS UNIT
14 SP TERMINAL UNIT
1 nsp MAIN CHASSIS 1 *
2nspBOTTOM COVER 1 *
3 00D1040352005 FOOT 4
4 00D4610385001 RUBBER PAD 4
5 406310003205D BACK PANEL JP 1 *
5 406310003212D BACK PANEL E2 1 *
5 406310003229D BACK PANEL E3 1 *
6 00D2033983008 AC INLET JP
6 00D2033996008 AC INLET (2P) E2,E3 1
7 00D4210851003 FAN 2410RL04WS10 1
8 nsp FAN BRACKET 1
9 nsp FAN GUARD PG-24-02 1 *
10 00D2051409001 1P SP TERMINAL RED 2
11 00D2051410003 1P SP TERMINAL BLUE 2
12 00D4620185000 SP WASHER (A) 4
13 00D4620186009 SP WASHER (B) 4
15 183010007002D (E2) AM FM TUNER E2 1 *
15 183010001004S (J) AM FM TUNER JP 1 *
15 183010002007S (E3) AM FM TUNER E3 1 *
16 00D2051116006 TERMINAL ASS 1
19 FGRCDCX1 SACD MECHA UNIT 1 *
20 nsp FRONT ANGLE 1 *
21 402410006102D FRONT PANEL 1 *
22 nsp MECHA HOLDER 1 *
23 411010002009D KNOB (F) ASSY 5 *
24 416510004005D WINDOW 1 *
25 443510002100D INNER PANEL (R) 1 *
26 nsp VOL PLATE 1 *
30 nsp PROTECTION SHEET (F) 1 *
★ 31
00D0090295087 25P FFC(1.0) 1 *
32 00D1431259005 REMOCON WINDOW 1
33 00D1431260007 REMOCON FILTER 1
34 423510002106D LENS (ON/ST) 1 *
35 411010003101D KNOB (ON/ST) ASSY 1 *
