Denon RCD-CX1 Service Manual

58
RCD-CX1
PARTS LIST OF P.W.B. UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
8U-210024A SYS/DAMP/DISP P.W.B. UNIT ASSY (for JP model)
8U-210024B SYS/DAMP/DISP P.W.B. UNIT ASSY (for E3 model)
8U-210024C SYS/DAMP/DISP P.W.B. UNIT ASSY (for E2 model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D2623602003 GP1UE271XKVF
IC201 232810008503D LME49720MA *
IC301 00D2623444902 TC74VHC08FT
IC302 8R2411001000D CX1 SYSTEM ROM ASSY M3062LFGPGP
IC303 00D2623082924 BD4730G-TR
IC304 00D2623498903 BR93L86RFVM-WTR
IC305 00D2623198902 TC74VHC157FT-EL +REF
IC306 00D2623410907 TC74VHCT08AFT
IC307 00D2622517908 SN74LV08APW-EL2 +REF
IC401 232810009506D NJM082BM *
IC501 235810011508D TC9273CFG-004(EL) *
IC502 231810019500D BA90BC0WFP *
IC503 00D2623727904 NJW1194V-TE1
IC504 00D2631231903 NJM78L07UA-TE1
IC505 00D2631232902 NJM79L07UA-TE1
IC506 00D2630995004 NJM4556AD +T
IC507,508 00D2631074908 OP275GSZ-REEL7 +C
IC509 00D2631277909 RC4580IDR
IC510 00D2623203907 TC7SHU04F-TE85L +REF
IC511 00D2690228009 GP1FAV30TK0F
IC701 00D2631074908 OP275GSZ-REEL7 +C
IC702 00D2631100005 KIA7805API-U/P
IC703 00D2631099006 KIA7905PI-U/P
IC704 00D2622977904 BA18BC0FP-E2 +C
IC705 235010012004D DA428440F-E *
IC707 00MHC10011090 NJM4558M-TE1
TR101,102 00D2730490904 2SC2412KFD6T146E
TR103 00D2730464901 KTC3875S-GR-RTK/P
TR203,204 00D2690082902 DTC114EKT96 +C
TR205,206 00D2730460905 KTC2875-B-RTK/P
TR207 00D2690083901 DTA114EKT96 +C
TR208 00D2690082902 DTC114EKT96 +C
TR210 00D2730460905 KTC2875-B-RTK/P
TR212 00D2730460905 KTC2875-B-RTK/P
TR213 00D2690082902 DTC114EKT96 +C
TR214 00D2690083901 DTA114EKT96 +C
TR215 00D2690082902 DTC114EKT96 +C
TR301 00D2740188905 2SD1858TV2(Q/R)
TR302 00D2690184907 KRA102S-RTK/P (10K-10K)
TR303,304 00D2690192902 KRC102S-RTK/P (10K-10K)
TR401-404 00D2750038045 2SK369 (BL)/(GR)-C
TR501,502 00D2690066902 DTC323TKT96 +C
TR503 00D2690083901 DTA114EKT96 +C
ご注意：
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
