Denon RCD-CX1 Service Manual

59
RCD-CX1
TR504,505 00D2690144905 DTC114YKA-T146 +C
TR506,507 00D2690066902 DTC323TKT96 +C
TR701 00D2690088906 DTC114TKT96 +C
TR702 00D2730458904 KTC3200-BL-AT/P
TR703 00D2710301903 KTA1268-BL-AT/P
TR704,705 00D2730488000 2SC4614 (HFE S/T)
TR706 00D2730384900 2SC2412KT96(S) +C
TR707 00D2710238908 2SA1037KT146S +C
TR708 00D2730423007 2SC4793-Y
TR709 00D2750042905 2SK373(Y)TPE2
TR710 00D2730384900 2SC2412KT96(S) +C
TR711 00D2690144905 DTC114YKA-T146 +C
TR712 00D2690082902 DTC114EKT96 +C
D201 00D2760684900 RB051L-40TE25 +C
D301-304 00D2760794900 KDS160-RTK/P
D401,402 00D2760794900 KDS160-RTK/P
D501,502 00D2760794900 KDS160-RTK/P
D504,505 00D2760750902 RB521S-30TE61 +REF
D506,507 00D2760794900 KDS160-RTK/P
D701,702 00D2760773905 RB501V-40 +2125
D703-707 00D2760794900 KDS160-RTK/P
D708,709 203850010506S SJPA-D3 *
D710,711 204850008506S RB160M-60 *
D712,713 203850010506S SJPA-D3 *
D714,715 204850008506S RB160M-60 *
D716,717 00D2760794900 KDS160-RTK/P
ZD101 00D2760624902 MTZJ2.0A T77
ZD104 00D2760762945 MTZJ36B T77
ZD301 00D2760798919 UDZS6.8B-TE17
ZD302 00D2760683943 UDZS3.6B-TE17
ZD701 00D2760683969 UDZS12B-TE17 +C
LD101 00D3939667003 SLA-360LT3F(XE)
LD102 00D3939656001 SLI343DU3F (ORG)
TH701,702 00D2790052007 NTPAD8R0LDNB0
FL101 00D3938093005 FL TUBE(8BT258GINK)
RESISTORS GROUP
R131 00D2412315912 RD14B2E100GFRST
R154 00D2412315912 RD14B2E100GFRST
R515,516 00D2350130903 CHIP EMIFIL(11A121) +1608
R560 00D2442051961 RS14B3A101JNBST(S)
R564 00D2442051974 RS14B3A102JNBST(S)
R565 00D2442051961 RS14B3A101JNBST(S)
R569 00D2442051974 RS14B3A102JNBST(S)
R713 00D2412381946 RD14B2E472JNBST
R721 00D2412381946 RD14B2E472JNBST
R727,728 00D2432099001 RW99A3H4R7K
R730 00D2412376964 RD14B2E470JNBST
R736 00D2412313985 RD14B2E4R7JFRST
Ref. No. Part No. Part Name Remarks Q'ty New
