83
RCD-CX1
PARTS LIST OF SACD MECHANISM
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
1A nsp SACD/DVD MECHA UNIT 1
1 - MECHA BASE ASS'Y 1
2 00D9KA2A760 TRAY ASSY 1
3 nsp MECHA FRAME 1
4 nsp HOUSING ASSY 1
5 00D9KA2G973 CAM GEAR 1
6 00D4240280505 SLIDE CAM 1
7 00D9KA2G974 DOUBLE PULLY 1
8 00D9KA2A762 L.MOTOR ASSY 1
9 00D4210845006 ROLLER 2
10 00D9KA2A763 PU-U/D-MOTOR ASSY 1
11 00D9KA2G985 WORM WHEEL 1
12 nsp TRAY HOLDER L 1
13 nsp TRAY HOLDER R 1
14 00D9KA2G969 BELT GEAR FRONT 1
15 00D9KA2G970 BELT GEAR REAR 1
16 00D9KA2G968 BELT FIRST 1
17 00D9KA2G971 BELT SECOND 1
18 00D9KA2G972 BELT THIRD 1
19 00D9KA2A764 TOP-PLATE ASSY 1
20 nsp MOTOR BRACKET ASS'Y 1
22 nsp CAM HOLDER 1
24 nsp SW BRACKET 1
25 nsp REAR BRACKET ASS'Y 1
26 00D4630973202 CAM SPRING 1
28 00D4630975006 SHAFT SPRING 6
30 00D4350137108 ROLLER SHAFT 1
32 nsp SLIDE SHAFT 1
33 00D9KA2A692A TRAVERSE MECHA ASS'Y 1
36 00D4230084009 TIMING BELT 1
37 00D4620184001 DAMPER 3
38 00D4210846005 O RING 2
40 00D4630976306 BOSS SPRING 1
41 nsp 2x3CBS-B 3
42 nsp 2x4CBS-B 7
43 nsp 2x6CFS-B 1
44 0RD4713003002 2.6x3CBS-B 2
45 nsp 2.6x5CFS-B 2
46 nsp 3x5CBS-B 27
47 nsp 2.6x5CBTS(S)-Z 1
49 00D4751190016 SLIT WASHER 1.7x3.2x0.5 1
50 00D4751157091 SLIT WASHER 3.1x5.4x0.5 3
51 00D4751190003 SLIT WASHER 3.1x12.0x0.5 2
52 00D4751161016 POLY WASHER 4.1x6.5x0.5 1
53 0RD4761003009 3E RING 1
54 nsp 2x6CBTS(P)-Z 1
58 00D9KC1H011 SCR-DAMPER 4
59 00D9KC2G083 DAMPER-IDLE 4
To Next Page
