Denon RCD-CX1 Service Manual

66
RCD-CX1
8U-210025A SMPS/SPT P.W.B. UNIT ASSY (for JP model)
8U-210025B SMPS/SPT P.W.B. UNIT ASSY (for E3 model)
8U-210025C SMPS/SPT P.W.B. UNIT ASSY (for E2 model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 231810020104D STR-X6759N(LF1905) JP,E3 *
z IC801 231810021107D STR-X6768N(LF1905) E2 *
IC802 00D2622977946 BA33BC0FP-E2 +REF
IC803 00D2631100063 KIA7809API-U/P
z IC804 00D2623047008 PC123Y22
IC805 00D2631279907 SI-8008TM
IC806 00D2631099022 KIA7912PI-U/P
IC807 00D2631100021 KIA7812API-U/P
IC808 00D2631099022 KIA7912PI-U/P
IC809,810 00D2631279907 SI-8008TM
TR801 00D2730464901 KTC3875S-GR-RTK/P
TR802 00D2730464901 KTC3875S-GR-RTK/P JP,E3
TR803,804 00D2730464901 KTC3875S-GR-RTK/P
z D801 203050014100S RBV-406H *
D802 00D2760758001 SARS03
D803-805 203850008503S SJPX-F2 *
D806 00D2760794900 KDS160-RTK/P
D807-815 00D2760750902 RB521S-30TE61 +REF
D816 00D2760794900 KDS160-RTK/P
D817-819 203850008503S SJPX-F2 *
D820 203050013107S FMXB-2102 *
D821 203850008503S SJPX-F2 *
D822 00D2760832008 FMX-G22S
D823 203850012502S SJPB-L4 *
D824 00D2760773905 RB501V-40 +2125
D825 00D2760794900 KDS160-RTK/P
D826 00D2760773905 RB501V-40 +2125
D827,828 203850012502S SJPB-L4 *
ZD801 00D2760798922 UDZS18B-TE17 JP,E3
ZD802 00D2631185907 TL431ACLP
z TH801 00D2790045001 NTPAJ6R0LDKB0
RE I T O R ROUP
S S S G
z R801,802 129550003504S RM73B2E115JT(HV732B) *
R803,804 129550006503S RM73B2B333JT JP,E3 *
R803,804 129550006510S RM73B2B473JT E2 *
R805 00D2442675716 RS14B3D683JNBF (ERG)
R810 nsp RM73B2B100JT +3216
R811 00D2432094006 RW99=3DR12JF
R812 00D2432094035 RW99=3DR10JF JP,E3
R823,824 nsp RM73B2B0R0KT +3216
R825-828 nsp RM73B2B223JT +3216
R837,838 nsp RM73B--243FT_1608
R839 nsp RM73B--273FT_1608
R840 nsp RM73B--302FT +1608
R860 nsp RM73B2B0R0KT +3216 JP,E3
R860 129550006510S RM73B2B473JT E2 *
