Denon RCD-CX1 Service Manual

7
RCD-CX1
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
TOP PANEL
SIDE PANE
L
TOP ANGLE
SW POWER UNIT FRONT PANEL SUB ASS
Y
Refer to "DISASSEMBLY Refer to "DISASSEMBLY
2.SW POWER UNIT" 1.FRONT PANEL SUB ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
SW POWER UNIT DISPLAY UNIT
(Ref. No. of EXPLODED VIEW : 1) (Ref. No. of EXPLODED VIEW : 3-1)
VOLUME UNIT SUB ASSY
SHIELD BRACKE
T
(Ref. No. of EXPLODED VIEW : 3-2)
POWER SW UNIT
(Ref. No. of EXPLODED VIEW : 3-3)
FRONT PANEL SUB ASS
Y
BACK PANEL ASS
Y
HEAD PHONE UNIT
Refer to "DISASSEMBLY Refer to "DISASSEMBLY (Ref. No. of EXPLODED VIEW : 3-8)
4.FRONT PANEL SUB ASSY" 3.BACK PANEL ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
DISPLAY UNIT FAN
(Ref. No. of EXPLODED VIEW : 3-1) (Ref. No. of EXPLODED VIEW : 3-2)
VOLUME UNIT SUB ASSY AM FM TUNER
(Ref. No. of EXPLODED VIEW : 3-2) (Ref. No. of EXPLODED VIEW : 3-2)
POWER SW UNIT AC INLET SUB ASSY
(Ref. No. of EXPLODED VIEW : 3-3) (Ref. No. of EXPLODED VIEW : 3-2)
HEAD PHONE UNIT SP TERMINAL UNIT
(Ref. No. of EXPLODED VIEW : 3-8) (Ref. No. of EXPLODED VIEW : 3-5)
TOP PANEL BRACKE
T
FRONT ANGLE
SACD MECHA ASS
Y
Refer to "DISASSEMBLY
5.SACD MECHA ASSY"
and "EXPLODED VIEW"
SACD MECHA UNIT
(Ref. No. of EXPLODED VIEW : 2-3)
MAIN UNIT SUB ASS
Y
Refer to "DISASSEMBLY
6.MAIN UNIT SUB ASSY"
and "EXPLODED VIEW"
MAIN UNIT SUB ASSY
(Ref. No. of EXPLODED VIEW : 2-2)
