Denon RCD-CX1 Service Manual

70
RCD-CX1
8U-310008 DRIVE/SACD/DAC P.W.B. UNIT ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D2631205900 PQ012FZ01ZP +C
IC102 00D2623591907 BD7956FS-E2
IC103 00D2623402902 BR24L32F-WE2 +C
IC104 00D2630615902 BA15218F-DXE2 +C
IC105 00D2631212906 KIA7805AF-RTF/P
IC106 8R2481001700D FE/BE ROM SUB ASSY EN29LV320AB-70TCP :
VER100170
*
IC107 00D2623339907 SN74LVC139APWR +REF
IC108 00D2623682007 MN2DS0009VP
IC109 00D2623594001 EM638165TS-7G
IC110 00D2622641900 SN74LV541APW-EL2 +C
IC111 00D2622514901 SN74LV138APW-EL2 +C
IC112 00D2623594001 EM638165TS-7G
IC113,114 00D2623242900 SN74LV273APW-EL2 +REF
IC115 00D2630615902 BA15218F-DXE2 +C
IC117 00D2623627907 TC7SZ125F(TE85L,F)
IC501 246010004607S M12L16161A-7TG
IC502 00D2623217003 CXD2753R +C
IC503 00D2622977917 BA25BC0FP-E2
IC504 00D2623629002 DXP6001AF-G
IC505 00D2623198902 TC74VHC157FT-EL +REF
IC506-508 00D2623203907 TC7SHU04F-TE85L +REF
IC510 00D2622517908 SN74LV08APW-EL2 +REF
IC511 00MHC008005KY TC7WHU04FU TRIPLE INVERTER
IC512 00D2623203907 TC7SHU04F-TE85L +REF
IC701 00D2623674002 LC4032V-75TN48C-DE01
IC702 00D2623338908 DSD1796DBR
IC703 00D2622977946 BA33BC0FP-E2 +REF
IC704 00D2631212906 KIA7805AF-RTF/P
IC708-710 00D2631074908 OP275GSZ-REEL7 +C
TR101 00D2720160901 2SB1132T100Q +C
TR102,103 00D2750109903 2SK3019-TL
TR104 00D2690229901 DTC143TUAT106
TR105 00D2720160901 2SB1132T100Q +C
TR106 00D2690229901 DTC143TUAT106
TR107,108 00D2730487904 2SC2412K_T146R
TR109 00D2750109903 2SK3019-TL
TR110,111 00D2690082902 DTC114EKT96 +C
TR112 00D2710259903 2SA1162-GR(TE85L)
TR113 00D2690082902 DTC114EKT96 +C
TR114 00D2730487904 2SC2412K_T146R
TR115 00D2750109903 2SK3019-TL
TR116 00D2740204902 2SD999(CM/CL)-T1 +C
TR117 00D2720166905 2SB798(DL/DK)-T1 +C
TR118 00D2730487904 2SC2412K_T146R
TR119 00D2740204902 2SD999(CM/CL)-T1 +C
TR120 00D2720166905 2SB798(DL/DK)-T1 +C
TR701 00D2730384900 2SC2412KT96(S) +C
D103 00D2760717903 1SS355 TE-17 +C
D501 00D2760717903 1SS355 TE-17 +C
ご注意：
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
