DISASSEMBLY
• Disassemble in order of the arrow of the gure of following ow.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling" it.
• If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly
as they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
HEAT SINK SUB ASSY
Refer to
"DISASSEMBLY
4. HEAT SINK SUB ASSY"
and
"EXPLODED VIEW"
HEAT SINK
(Ref. No. of EXPLODED VIEW : 18)
TOP COVER
FRONT PANEL ASSY
Refer to
"DISASSEMBLY
2. FRONT PANEL SUB ASSY"
and
"EXPLODED VIEW"
FRONT PANEL
(Ref. No. of EXPLODED VIEW : 6)
CD MECHA ASS'Y
Refer to
"DISASSEMBLY
3. CD MECHA ASS'Y"
and
"EXPLODED VIEW"
CD MECHA
(Ref. No. of EXPLODED VIEW : P8)
REAR PANEL ASSY
Refer to
"DISASSEMBLY
5. REAR PANEL ASS'Y"
and
"EXPLODED VIEW"
REAR PANEL
(Ref. No. of EXPLODED VIEW : 21)
POWER UNIT ASSY
Refer to
"EXPLODED VIEW"
6. POWER UNIT ASS'Y"
and
"EXPLODED VIEW"
POWER UNIT
(Ref. No. of EXPLODED VIEW : P1)
MCU PCB UNIT ASSY
Refer to
"EXPLODED VIEW"
7. MCU PCB UNIT ASSY"
and
"EXPLODED VIEW"
MCU PCB UNIT
(Ref. No. of EXPLODED VIEW : P3)
TRANS
Refer to
"EXPLODED VIEW"
8. TRANS"
and
"EXPLODED VIEW"
TRANS
(Ref. No. of EXPLODED VIEW : P6)
LOADER PANEL ASSY
Refer to
"DISASSEMBLY
1. LOADER PANEL ASSY"
and
"EXPLODED VIEW"
LOADER PANEL
(Ref. No. of EXPLODED VIEW : 3)
