16
(3) Remove the screws.
(4) Disconnect the connector wires.
View from bottom
HEAT SINK SUB ASSY
CBAM
Direction of photograph: C
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in HEAT SINK SUB ASSY.
