74
Pin No Port Name Port Name I/O
Status
Note
Pull-U/D init. stby Act.
65 P71 N.C O L Open
66 P72 N.C O L Open
67 P73 N.C O L Open
68 P74 N.C O L Open
69 P80 BOOT I PU - - L
70 P82 N.C O L Open
71 P83 LRCK1 O L L H/L to Oasis (IC16)
72 AM1 VDD3.3V P
73 X2 X2 O Oscilator connection 9MHz output
74 DVSS GND G
75 X1 X1 I Oscilator connection 9MHz input
76 DVCC3A VDD3.3V P
77 P75 USB_OC I PU - - L USB over current detection
78 P76 N.C O L Open
79 D+ USB+ I/O
80 D- USB- I/O
81 AM0 VDD3.3V P
82 P77 USB-DETECT I - - L USB Detect
83 DVSS3A GND G
84 PF0 / TXD0 N.C O L Open
85 PF1 / RXD0 N.C O L Open
86 PF2 D+ DOWN O PD L - H USB D+ LINE RESET
87 PF3 / TXD1 USB-TX O L L H/L to HOST MCU (IC11)
88 PF4 / RXD1 USB-RX I - - H/L to HOST MCU (IC11)
89 PF5 N.C O L
90 PN1 CP-SDA I/O PU L L H/L to Apple Chip (WWI) IC42(MFI341S2164)
91 PN2 CP-CLK O PU L L H/L to Apple Chip (WWI) IC42(MFI341S2164)
92 PN3 USB-BCK O L L H/L to Oasis (IC16)
93 PN4 UBS-DATA O L L H/L to Oasis (IC16)
94 PN5 USB-GATE O L L H to Oasis (IC16)
95 DVCC3A VDD3.3V P
96 PG3 N.C I Open
97 PG2 DREQ(MP3REQ) I PD - - L to Oasis (IC16)
98 PG1 N.C I PU
99 PG0 N.C I Open
100 DVSS3A GND G
To Next Page
