Denon RCD-M39 Service Manual

DIGITAL INPU
DIGITAL INPU PCB ASS'Y
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model EK : U.K. model E1C : China model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC14 00D9430005605 REGULATOR IC (+8V) HVIKA78L08AZT
IC15 943231101250D IC , REGULATOR (-8V, TO-92, TAPPING) CVILM79L08TA *
IC16 943231101210D I.C , REGULATOR(SOT-223) CVIKIA1117BS33
IC32 943239100820D I.C , DC DC CONVERTER(3A,700KHZ,SOP-8P) CVIDB1230HETR
IC51 943236101350D I.C , DIR/DIT(WITH ADC,LQFP-48P) CVIPCM9211PTR *
IC53 00D2623727904 I.C , 2CH VOLUME CVINJW1194V
IC54 943231101210D I.C , REGULATOR(SOT-223) CVIKIA1117BS33
IC57 943239100690S I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR
IC61 00MHC10102090 I.C , OP AMP (JRC) HVINJM2068MDTE1
IC62 235810050503S I.C , OP AMP (JRC, 2CH Input) CVINJM4565MTE1
IC91 00D9430206908 REGULATOR IC (12V OUTPUT LOW DROP) HVIKIA78R12PI
IC93 00D2631100050 I.C,REGULATOR(+8V,T0220IS) HVIKIA7808API
D111 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D113 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D501 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T EK HVD1SS355T
D502-504 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D506 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D601 00D2760717903 DIODE , CHIP , SWITCHING 1SS355T HVD1SS355T
D909 00D9430060501 DIODE , RECTIFIER 1SR159 HVD1SR159-200
D913 00D9430060501 DIODE , RECTIFIER 1SR159 HVD1SR159-200
D945,946 00D9430060501 DIODE , RECTIFIER 1SR159 HVD1SR159-200
Q501 943216500020S T.R,RT1N141C(10K-10K) EK CVTRT1N141C
Q602 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q605,606 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B
Q607 943215500140D T.R , RT1P144C(10K-47K) CVTRT1P144C
Q608 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
CAPACITORS GROUP
C140,141 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C144,145 943134502140D CAP, ELECT(TOSHIN, UTSP, 16V/220uF), 85'C) CCEA1CUTSP221T *
C146-152 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C153 00D2544694912 ElECT CAP (220uF/25V, RFO) CCEA1ERFO221T
C154 943134502170D CAP , ELECT(TOSHIN, UTSP, 50V/100uF, 85'C) CCEA1HUTSP101T *
C313,314 nsp CAP, CHIP(2012, 25V/22uF, X7R) CCUC1E226KC
C315 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C317,318 nsp CAP, CHIP(2012, 10V/2.2uF) CCUC1A225KC
C319 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C320 nsp CAP, CHIP(2012, 25V/22uF, X7R) CCUC1E226KC
C321 nsp CAP,CHIP(1608,50V/1500pF) CCUS1H152KC
C322 nsp CAP, CHIP(2012, 25V/22uF, X7R) CCUC1E226KC
C323 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C326,327 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C328,329 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C502 90M-EJ000020R CAP , ELECT CCEA1CKS220T
C503 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C504 nsp CAP, CHIP(1608, 50V/0.068uF) CCUS1H683KC
C505 nsp CAP,CHIP(1608,50V/4700pF) CCUS1H472KC
C506 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C507 nsp CAP, ELECT(50V/22uF) CCEA1HH220TC
C508 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C509 nsp CAP, ELECT(16V/22uF) CCEA1CH220TC
C510 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA
C511 nsp CAP,CHIP(1608,50V/18pF) CCUS1H180JA
C513 nsp CAP, ELECT(16V/22uF) CCEA1CH220TC
C514-516 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C517,518 nsp CAP, ELECT(50V/22uF) CCEA1HH220TC
C519 943134501980D CAP, ELECT(16V/100uF) CCEA1CH101TC
C521 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C522 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC
C523 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C524,525 nsp CAP, ELECT(50V/4.7uF) CCEA1HH4R7TC
C526 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C527 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC
C528,529 00D2544693942 CAP, ELECT(50V/220uF,ELNA/RFO) CCEA1HRFO221E
C531 943134501980D CAP, ELECT(16V/100uF) CCEA1CH101TC
C532 nsp CAP, ELECT(50V/22uF) CCEA1HH220TC
C533-535 nsp CHIP CAP CCUS1H181JA
C536 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C537 nsp CHIP CAP CCUS1H181JA
C538 943134502030D CAP, ELECT(50V/10uF) CCEA1HH100TC
C539 nsp CHIP CAP CCUS1H181JA
C540,541 943133501490D POLYPROPYLNE SHINYEI (AQUA, 222) CCMP2A222JS07T *
C542 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C544 134050059238S CAP , ELECT (ELNA RFG, 50V/220uF, 85'C, 10X16) CCEA1HRFY221E
C545,546 nsp CAP, CHIP(1608, 6.3V/2.2uF) CCUS0J225KC
C547-449 nsp CAP, CHIP(1608, 50V/0.1uF)
CCUS1H104KC
C550 nsp CAP, CHIP(1608, 50V/0.1uF) E2, E3 CCUS1H104KC
C551 nsp CAP, ELECT(10V/470uF) E2, E3 CCEA1AH471TC
C552 nsp CAP, ELECT(16V/10uF) CCEA1CH100TC
C553 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C554,C555 nsp CAP, CHIP(1608, 50V/0.01uF) EK CCUS1H103KC
C556 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C557 90M-EJ000090R CAP , ELECT EK CCEA1AKS331T
C558 nsp CAP, ELECT(16V/10uF)-S EK CCEA1CKS100TC
C559 nsp CAP, CHIP(1608, 50V/0.1uF) EK CCUS1H104KC
C560 90M-EJ000020R CAP , ELECT EK CCEA1CKS220T
C561 nsp CAP, CHIP(1608, 50V/0.1uF) EK CCUS1H104KC
C562 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC
C563 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C564 nsp CAP, ELECT(16V/10uF) CCEA1CH100TC
C565 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C566,567 943134502030D CAP, ELECT(50V/10uF) E2, E3 CCEA1HH100TC
C568 nsp CAP, ELECT(16V/10uF) CCEA1CH100TC
C569 nsp CAP, CHIP(1608, 50V/0.01uF) EK CCUS1H103KC
C570-572 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C573 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
C574 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C575 90M-EJ000020R CAP , ELECT EK CCEA1CKS220T
C576,577 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
C599 90M-EJ000090R CAP , ELECT EK CCEA1AKS331T
C605 nsp CAP, ELECT(50V/22uF) CCEA1HH220TC
C606,607 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC
