aXcs
®
Wall/Cabinet Unit
2 Installation, Operation and Care Manual
Section I Introduction
This manual contains installation, operation and care
instructions and user service information for the
DentalEZ
®
aXcs
®
Wall/Cabinet Unit.
The aXcs Wall/Cabinet Unit is available in two stan-
dard configurations: DWM - doctor's control with
long arm for wall mounting and utility service center
(USC), and DCM - doctor's control with short arm
for cabinet mounting and cabinet mounted utilities
(does not include umbilical or utility service center).
The aXcs DWM/DCM is designed to provide
trouble-free service when installed, operated and
maintained according to the procedures set forth in
this manual.
To ensure correct installation, carefully read all the
procedure instructions contained in this manual
paying close attention to all notes, cautions and
warnings.
Before proceeding, please review the illustration
below to become familiar with the basic components
of the aXcs DWM/DCM*.
After the DWM/DCM is installed, please review the
operation procedures and care guidelines with the
doctor's staff. Then leave this manual in the
doctor's office for the doctor's and the staff's future
reference.
Delivery Head
Umbilical
Utility Service Center
Foot Control
Adjustable Arm
Fixed Arm
Wall Mount
Instrument Hanger
Mounting Board
(Optional)
*Components of DWM shown.
BASIC COMPONENTS
