Derby cycle Impulse 2.0 pedelec - 8.3.1.3 Charging the seat tube battery with charger type 2; 8.3.1.4 Charging the down tube battery with charger type 3

Original User Guide | Impulse 2.0 Pedelec Version 3 EN-77
8.3.1.3 Charging the seat tube battery with charger type 2
1. Connect the power cable to the battery charger.
2. Remove the protective cap on the battery.
3. Connect the charging cable to the battery charging socket until it engages.
4. Insertthemainsplugintoapowersocket.TheredLEDbrieylightsup
, then the
greenLEDashessteadily
.
5. Thechargerswitchesooncethebatteryisfullycharged.ThegreenLEDis
permanently on
.
6. Remove the power cable from the socket after completing the charging process.
7. Remove the charging cable from the battery charging socket.
8. Replace the protective cap.
8.3.1.4 Charging the down tube battery with charger type 3
1. Connect the power cable to the battery charger.
2. Remove the protective cap on the battery.
3. Connect the charging cable to the battery charging socket until it engages.
4. Insert the mains plug into a power socket.
5. Remove the power cable from the socket after completing the charging process.
6. Remove the charging cable from the battery charging socket.
7. Replace the protective cap on the battery charging socket.
