Derby cycle Impulse 2.0 pedelec - 10. Torque settings

EN-86 Original User Guide | Impulse 2.0 Pedelec Version 3
Screwxing Thread Tightening torque (Nm)
Pedal crank screw M6 40
Pedal 9/16 40
Front axle nut General 25 – 30
Rear axle nut
General
35 – 40
Ahead stem angle adjustment M6 8 – 10
Ahead stem handlebar clamp M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Ahead stem steerer tube M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Bar end, external clamp M5 / M6 M5: 5 / M6: 10
Saddle clamp bottom M5 / M6 / M8 M5: 5 / M6: 10 / M8: 20
Saddle clamp top M5 / M6 / M7
/ M8
M5: 5.5 / M6: 5.5 / M7: 14 /
M8: 20
Rim brake shoe M6 10
Sliding drop-outs M10 16
Disc brake calliper, Shimano, IS and PM M6 6 – 8
Disc brake calliper, AVID, IS and PM M6 8 – 10
Disc brake calliper, Magura, IS and PM M6 6
Gear lever clamp M5 5
Brake lever clamp M5 Ref. manufacturer's spec.
Cassettexingring N/A 30 – 40
Screw-on handlebar plugs M4 / M5 M4: 3 / M5: 5
Motor housing M5 5.9
Motor bolts M8 25
Luggage rack M5 / M6 M5: 5 – 6 / M6: 8 – 10
10. Torque settings
DANGER
Only use proper tools to tighten screws and bolts. Observe the
speciedtorquesetting.Thecomponentmanufacturer'storque
settings take precedence (where available). Failure to comply can
result in screws/bolts becoming loose, tearing away or fracturing. If
thathappenswhileridingthebike,componentsmaycomeoand
youcouldhaveaseverecrash.Ifxingsareovertightenedother
components can also be damaged. Tighten all safety-relevant screws
and bolts with a torque wrench. This indicates the corresponding
torque in newton metres (Nm).
If no values are shown on the component or component manuals, use the
torque settings from the following table.
