ENCLOSURE MATERIAL—
Copper-free aluminum (painted) or Stainless
Steel (316/CF8M Cast).
VIBRATION—
Conformance per FM 3260: 2018, MIL-STD
810C (Curve AW).
WIRING—
Field wiring screw terminals are UL/CSA rated
for up to 14 AWG wire, and are DIN/VDE rated
for 2.5 mm
2
wire. Screw terminal required torque
range is 3.5 in.-lbs. (0.4 N·m).
Important: 18 Vdc minimum must be available
at the detector. For
ambient temperatures
below
–10°C (14°F) and above +60°C (140°F) use field
wiring suitable for both minimum and maximum
ambient temperature.
THREAD SIZE—
Conduit connection: Four entries, 3/4 inch NPT or
M25.
Conduit seal not required.
SHIPPING WEIGHT (APPROXIMATE)—
Aluminum: 7 pounds (3.2 kilograms).
Stainless Steel: 13.8 pounds (6.3 kilograms).
Mounting Arm (AL): 6 pounds (2.75 kilograms).
Mounting Arm (SS): 14 pounds (6.4 kilograms).
WARRANTY PERIOD—
5 years.
CERTIFICATION—
For complete approval details, refer to the
appropriate Appendix:
Appendix A - FM
Appendix B - CSA
Appendix C - ATEX
Appendix D - IECEx
Appendix E - Additional Approvals
Appendix F - Declaration of Conformity
REPLACEMENT PARTS
The detector is not designed to be repaired in
the field. If a problem should develop, refer to the
"Troubleshooting" section. If it is determined that
the problem is caused by an electronic defect,
the device must be returned to the factory for
repair.
REPLACEMENT PARTS
Part Number Description
009208-003
o
i
Replacement kit for X3302
(5 Black Reflector Plates)
with Inspector Connector and Monitor
010831-002
o
i
Replacement kit for X3302
(5 Stainless Steel Reflector Plates)
with Inspector Connector and Monitor
007307-003
Replacement o
i
Reflector Plate for X3302 with
Black plate (requires Inspector Connector to
calibrate)
010830-002
Replacement o
i
Reflector Plate for X3302
with Stainless Steel plate (requires Inspector
Connector to calibrate)
NOTE: Refer to instruction manual 95-8530 to determine the
correct Replacement
o
i
Reflector Plate.
DEVICE REPAIR AND RETURN
Prior to returning devices, contact the nearest
local Detector Electronics office so that a Return
Material Authorization (RMA) number can be
assigned. A written statement describing the
malfunction must accompany the returned
device or component to assist and expedite
nding the root cause of the failure.
Pack the unit properly. Always use sufficient
packing material. Where applicable, use an
antistatic bag as protection from electrostatic
discharge.
NOTE
Det-Tronics reserves the right to apply a
service charge for repairing returned
product damaged as a result of improper
packaging.
Return all equipment transportation prepaid to the
factory in Minneapolis.
NOTE
It is highly recommended that a complete
spare be kept on hand for eld replacement
to ensure continuous protection.
®
