NOTE: While in the Program Mode, if there is no magnetic switch interaction after 4 consecutive
menu scrolls, the sensor will automatically revert to normal operating condition. While changing
values inside menu items, if there is no magnet activity after 3-4 seconds the sensor will
revert to the menu scroll.
(Exception to this is with “Signal Output Check” mode.)
3.2 Operator Interface
The operating interface is menu-driven via the two magnetic program switches located under the target marks
of the sensor housing. The two switches are referred to as “PGM1” and “PGM2”. The menu list consists of
three major items that include sub-menus as indicated below. (Refer to the complete Software Flow Chart.)
Normal Operation
Current Reading and Fault Status
Calibration Mode
AutoZero
AutoSpan
Program Mode
View Sensor Status
Sensor Model Type
Current Software Version
Gas Type
Range of Detection
Serial ID address
AutoSpan Level
Days From Last AutoSpan
Remaining Sensor Life
Gas Factor
Raw Active Counts
Raw Reference Counts
4-20mA Output
Input Voltage Supply
Sensor Temperature
Set AutoSpan Level
Set Gas Type & Range
Set Gas Factor
Set Serial ID
Set Sensor Gain
Signal Output Check
Restore Default Settings
