IR-700 Instruction Manual Rev. 4.3 Page 41 of 46
that the detector will accurately detect gas after exposure to IP66 conditions
and it is recommended to check/adjust calibration following IP66 exposure
events.
Safety Approvals:
CCSAUS Performance Requirements to ANSI/UL 12.13.01:2013
CE Marking
SIL2 FMEDA Rating
Warranty: Plug-in detector – 2 years pro-rated
Transmitter – 2 years
Environmental Specifications
Operating Temperature: -40°F to +167F°; -40°C to +75°C
Operating Humidity: 0-100% RH (Non-condensing)
Operating Pressure: +/- 10% of Ambient Pressure (ie. 13.2 – 16.2 psig)
Air Velocity Limits: < 6 meters/second
Storage Specifications
Storage Temperature: -40°F to +167F°; -40°C to +75°C
Storage Humidity: 0-99% RH (Non-condensing)
Storage Pressure: 10 – 16 psig
Storage Duration: For detectors and all associated parts - 10 years
Mechanical Specifications
Dimensions: Sensor Assembly Only
7.8"H x 2.125" Dia.; 198mmH x 54mm Dia.
Stainless Steel Junction Box
12.5"H x 6.1"W x 4"D; 317mmH x 155mmW x 101mmD
Mounting holes (J-box) 5.5"; 140mm center to center
Aluminum Junction Box
13"H x 6.1"W x 4"D; 330mmH x 155mmW x 101mmD
Mounting holes (J-box) 5.5"; 140mm center to center
Mini Stainless Steel Junction Box
11"H x 4.24"W x 3.5"D; 279mmH x 108mmW x 89mmD
Mounting holes (J-box) 3.5"; 89mm center to center
Weight: 2 lbs; 0.907kg (sensor only)
6 lbs; 2.72kg (w/aluminum j-box)
9 lbs; 4.08kg (w/stainless steel j-box)
5 lbs; 2.27kg (w/mini stainless steel j-box)
