The voltage supply is now set up. After a few seconds, the door begins the calibration run. This is how
the door calculates the distance (the travel path) and the weight of the leaves. The door closes, opens
and closes again. From this point on- wards, the door is ready for operation.
With digital key switch:
Please refer to digital programme switch instruction manual.
(Without digital key)
SLT
SLT
6. Modifying the Parameters
You can use the potentiometers to adjust the closing speed, the opening speed and the hold-open time.
Press the test button to inspect and save your settings. You can use a maximum of 5 calibration runs.
Position the SLT potentiometer towards the right. A further 5 calibration runs can
now be executed.
If 5 calibration runs do not suffice, execute a run with the SLT positioned towards the
left.
If combination sensors are being used, set the SLT potentiometer to the
central position. If combination sensors are not being used, the SLT
potentiometer must be turned all the way to the left. The sensors, the batteries
and the lock can now be connected, after which the door is operational.
SLT
Without
combination
sensors
Inspecting
or saving
With combination sensors
(in Germany)
33
EN.22.04032019
