Devicor Neoprobe neo2000 - Input Controls Test Mode (ICTM)

neoprobe
TM
GDS Operation Manual
AW-000639 Page 25 of 38
Step
Procedure
Result
5
Diagnostic Mode: Press and hold
Dynamic/Binary Pitch Mode Selection
Button [4], press and release
Background Count Button [14].
A double Stop Beep sounds and
Background Count Readout displays
“diag”.
diag
6
Exit Diagnostic Mode - press and hold
Dynamic/Binary Pitch Mode Selection
Button [4], press and release Mute
Button [16].
Exits Diagnostic Mode.
Input Controls Test Mode (ICTM)
Verify input controls are operating properly:
Step
Procedure
Result
1
Press and hold down Binary
Pitch/Dynamic Pitch mode selection
button and press Mute button - -
release all buttons at once
Background count displays “diag”.
diag
2
Enter Input Controls Test Mode
(ictm) - Press and hold down Binary
Pitch/Dynamic Pitch mode selection
button and press Dynamic Pitch range
1000 button - - release all buttons at
once
Background count displays “ictm”.
ictm
3
Press and release buttons in order
listed below:
Continuous tone sounds and message
is displayed in Target Count Readout
[7]:
 Radionuclide
Bu0
 Target count
Bu1
 Background count
Bu2
 Mute
Bu3
 Binary pitch/dynamic pitch
mode
Bu4
 Count range 100
Bu5
 Count range 1,000
Bu6
 Count range 10,000
Bu7
 Count range 50,000
Bu8
4
To exit ITCM Mode, press and hold
Binary Pitch/Dynamic Pitch selection
button, and while holding it down,
press and release Background Count
button
A double chime tone is heard and
Background Count display displays
“diag”.
diag
5
Exit Base Diagnostic Mode - press
Exit Diagnostic Mode
Artwork No: AW-000639 Revision: A Artwork Status: Released Lifecycle Name: Artwork
PCO No: N/A ECN No: ECN-000214 Release Date: 10/09/2012 Effective Date: 10/09/2012
