DeVilbiss 7314P-D - Specifications;Classifications; Two-Year Limited Warranty

EN - 10 A-7314
SPECIFICATIONS/CLASSIFICATIONS
Size (including container) 8.3 H x 8.0 W x 8.5 D (21.1 cm x 20.3 cm x 21.6 cm) (not including AC to DC adapter)
Weight (including container) 7314P Series - 6.6 lb. (3 kg) (not including AC to DC adapter)
7314D Series - 4.3 lb. (2.0 kg)
Typical Operating Sound Level 55 dBA
Electrical Requirements
100-240V~, 50/60Hz, 1.2A max
; 12V ; 33 W Max
Vacuum Range
50-550 mm Hg +/- 10%*
Air Flow @ Pump Inlet: 27 LPM (free ow) typical (may be less when running from internal battery)*
Disposable Collection Container Capacity 800 ml (cc) with 2 lter options
Reusable Collection Container Capacity 1200 ml (cc)
Warranty
Two-years limited, excluding internal battery (7314P series only) and collection container
Internal Battery (7314P Series Only) 90-day
Approvals
IEC 60601-1:2005+AMD1:2012; EN 60601-1-2: 2015; ISO 10079-1:2015; IEC 60601-1-2:2014; IEC 60529:1989+AMD1:1999
+AMD2:2013; IEC 60601-1-6:2010; IEC 60601-1-11:2015;IP22
CONFORMS TO AAMI STD. ES 60601-1, AAMI STD. HA 60601-1-11, IEC STD. 60601-1-6, ISO STD. 10079-1
CERTIFIED TO CSA STD. C22.2 NO. 60601-1, NO. 60601-1-11, IEC STD. 60601-1-6, ISO STD. 10079-1
7314 Series complies with IEC 60601-1 3rd Edition
Environmental Conditions
Operating Temperature Range 32°F (0°C) - 104°F (40°C)
Operating Relative Humidity 0-95%
Operating Atmospheric Pressure 10.2 psi (70 kPa) - 15.4 psi (106 kPa)
Storage & Transport Temperature Range -40°F (-40°C) - 158°F (70°C)
Storage & Transport Relative Humidity 0-95%
Storage & Transport Atmospheric Pressure 7.3 psi (50 kPa) - 15.4 psi (106 kPa)
Equipment Classications
With respect to protection from electric shock Class II and internally powered
Degree of protection against electric shock Type BF Applied Parts
Degree of protection against ingress of liquids IP22 and ordinary power supply
Mode of Operation Intermittent Operation: 30 minutes on, 30 minutes off
Equipment not suitable for use in the presence of a ammable anaesthetic mixture with air or with oxygen or nitrous oxide.
ISO Classication
High Flow/High Vacuum
7314 series - Electrically powered medical suction equipment for non-transport use according to EN ISO 10079-1:2015
* Conditions may vary based on altitude above sea level, barometric pressure, and temperature.
TWO-YEAR LIMITED WARRANTY
The compressor portion of the DeVilbiss Vacu-Aide QSU Suction Unit 7314 Series (excluding internal rechargeable batteries and collection containers) is warranted to be free
from defective workmanship and materials for a period of two years from date of purchase. Internal rechargeable batteries are warranted for 90 days. Any defective part(s) will
be repaired or replaced at DeVilbiss Healthcare’s option if the unit has not been tampered with or used improperly during that period. Make certain that any malfunction is not
due to inadequate cleaning or failure to follow the instructions. If repair is necessary, contact your DeVilbiss Healthcare Provider or DeVilbiss Service Department for
instructions: U.S.A. 800-338-1988 or 814-443-4881, Europe +49-(0) 621-178-98-0.
NOTE– Be sure to retain a dated proof of purchase document to verify unit is within 2-year warranty period.
NOTE– This warranty does not cover providing a loaner unit, compensating for costs incurred in rental while said unit is under repair, or costs for labor incurred in repairing or
replacing defective part(s).
THERE IS NO OTHER EXPRESS WARRANTY. IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE DURATION OF THE EXPRESS LIMITED WARRANTY AND TO THE EXTENT PERMITTED BY LAW ANY AND ALL IMPLIED WARRANTIES ARE
EXCLUDED. THIS IS THE EXCLUSIVE REMEDY AND LIABILITY FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES UNDER ANY AND ALL WARRANTIES ARE
EXCLUDED TO THE EXTENT EXCLUSION IS PERMITTED BY LAW. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
OR THE LIMITATION OR EXCLUSION OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
Manufacturer’s Note
Thank you for choosing a DeVilbiss Suction Unit. We want you to be a satised customer. If you have any questions or comments, please send them to our address on the
back cover.
For Service Call Your Authorized DeVilbiss Healthcare Provider:
Phone Purchase Date Serial #
