Devolo Magic 1 WiFi 2-1 - Frequency range and transmitting power; Channels and carrier frequencies

49 Appendix
devolo Magic 1 WiFi
Technical specifications in the 2.4-GHz frequency range
5.3 Channels and carrier frequencies
Channels and frequencies in the 5-GHz band
Channels and frequencies in the 2.4 GHz band
Frequency range 2.4 GHz
IEEE standard 802.11 b
802.11 g
802.11 n
Indoor frequency range –
Indoor & outdoor fre-
quency range
2399.5 – 2484.5 MHz
Channel bandwidth 20 MHz (802.11 b/g)
20, 40 MHz (802.11 n)
Max. indoor transmissi-
on power (EIRP)
100 mW / 20 dBm
Max. transmitting po-
wer
100 mW / 20 dBm
Channel Carrier frequency
36 5180 MHz
40 5200 MHz
44 5220 MHz
48 5240 MHz
52 5260 MHz
56 5280 MHz
60 5300 MHz
64 5320 MHz
100 5500 MHz
104 5520 MHz
108 5540 MHz
112 5560 MHz
116 5580 MHz
120 5600 MHz
124 5620 MHz
128 5600 MHz
132 5660 MHz
136 5680 MHz
140 5700 MHz
Channel Carrier frequency
1 2412 MHz
2 2417 MHz
Channel Carrier frequency
